QMA M RA LMR 240 CRIMP
QMA M RA LMR 240 CRIMP

QMA M RA LMR 240 CRIMP

₹125

  1. Connector Type:
    • QMA Male Right-Angle Crimp: A male QMA connector with a right-angle design, intended for crimping onto LMR-240 coaxial cables.
  2. Cable Compatibility:
    • LMR-240 Coaxial Cable: The connector is designed to be used with LMR-240 coaxial cables, which are known for their low attenuation and high-frequency performance.
  3. Crimping Method:
    • Crimp: The connector is attached using a crimping tool. This process involves inserting the prepared LMR-240 cable into the connector and using a crimping tool to secure the connection mechanically.
  4. Material:
    • Body: Typically made from high-quality metals such as brass or stainless steel, often with nickel or gold plating to enhance conductivity and resistance to corrosion.
    • Contacts: Constructed from conductive materials with plating to ensure minimal signal loss and reliable performance.
  5. Impedance:
    • 50 Ohms: Designed to match the impedance of LMR-240 coaxial cables, which is essential for maintaining signal integrity and minimizing signal loss.
  6. Frequency Range:
    • High Frequency: QMA connectors are suitable for high-frequency applications, generally operating effectively from DC up to several GHz, depending on the specific design and application.
  7. Dimensions:
    • Right-Angle Design: The right-angle configuration aids in efficient cable routing and space management, especially in compact or constrained environments.
  8. Usage:
    • Applications: Commonly used in RF and microwave systems, including communication devices, antennas, and other electronic systems requiring reliable and compact RF connections.
    • Common Uses: Connecting RF components where a right-angle configuration helps with cable management and spatial constraints.
  9. Installation:
    • Tools Required: Crimping tool, cable stripper, and possibly a coaxial cable cutter.
    • Procedure: Strip the insulation from the LMR-240 cable, insert the cable into the connector, and use a crimping tool to compress the connector onto the cable. Ensure proper alignment to maintain signal integrity and secure the connection.
Categories: , , Tag:

The QMA M RA LMR 240 crimp connector is a right-angle male connector designed for use with LMR 240 coaxial cables. This connector utilizes a crimp attachment method to provide a secure and stable connection in RF systems. It is suitable for applications where an angled connection is necessary, such as in communication devices, antennas, and other high-frequency systems. The QMA M RA LMR 240 crimp connector is commonly used in environments where minimal signal loss and reliable performance are essential. Its durable construction ensures long-lasting performance in demanding RF applications. |

  • QMA M RA LMR 240 CRIMP is a male QMA connector with a right-angle (RA) design, intended for crimping onto LMR-240 coaxial cables.
  • “QMA” stands for Quick Mount Adapter, a type of RF connector known for its secure and quick-locking mechanism.
  • “M” indicates that the connector is male, featuring external pins that mate with a female QMA connector.
  • “RA” signifies a right-angle design, which allows the connector to change the direction of the cable connection by 90 degrees, making it suitable for tight spaces or specific routing needs.
  • “LMR 240” specifies the coaxial cable type compatible with this connector. LMR-240 is known for its low-loss performance, durability, and flexibility.
  • “CRIMP” indicates that the connector is designed to be attached to the cable using a crimping method, which involves compressing the connector onto the cable’s conductors.
