SMB M BH SOLDER
SMB M BH SOLDER

SMB M BH SOLDER

₹99

  1. Connector Type:
    • SMB Male Board Hole Solder: A male SMB connector designed for soldering to a PCB or cable, featuring pins or leads that are soldered onto the board.
  2. Pin Configuration:
    • Solder Pins: The connector has solder pins that fit into holes on a PCB or through a cable’s inner conductor. The soldering process ensures a permanent and stable electrical connection.
  3. Material:
    • Body: Made from durable metals such as brass or stainless steel, often plated with nickel or gold to improve conductivity and resist corrosion.
    • Contacts: Made from high-conductivity metals and may be plated to reduce signal loss.
  4. Cable Compatibility:
    • Flexible: Can be used with a variety of coaxial cables depending on the specific connector and soldering method.
  5. Impedance:
    • 50 Ohms: Typically designed for a 50-ohm impedance, though it’s essential to match the impedance with the application requirements.
  6. Frequency Range:
    • High Frequency: Suitable for high-frequency applications, effective up to several GHz depending on the specific connector design.
  7. Installation:
    • Soldering: The connector is attached to a PCB or cable using solder. The pins are inserted into holes or onto pads, and solder is melted around the pins to secure them.
    • Tools Required: Soldering iron and soldering materials are necessary for installation.
  8. Applications:
    • PCB Mounting: Ideal for mounting on PCBs in various electronic devices.
    • RF Communication Systems: Used in RF communication systems including antennas, transmitters, and receivers.
    • General Electronics: Suitable for various electronic and RF applications where a reliable soldered connection is required.
Categories: , , Tag:

The SMB male bulkhead connector with solder termination is designed for secure and reliable connections in RF applications. This connector is ideal for use in systems where a robust and durable connection is essential. The bulkhead design allows for easy panel mounting, ensuring a stable connection. The solder termination provides a secure and consistent connection, suitable for high-frequency applications. This connector is built to withstand various environmental conditions, making it a reliable choice for long-term use in communication systems. |

  • SMB M BH SOLDER is a male SMB connector intended for use where a soldering connection is preferred, typically with PCB mounting or direct cable connections.
  • “SMB” refers to the SMB series, which are compact RF connectors known for their snap-on coupling mechanism.
  • “M” denotes that the connector is male, meaning it has external pins that mate with female connectors.
  • “BH” stands for “Board Hole” or “Board Mount” indicating the connector is designed for mounting on a PCB.
  • “SOLDER” indicates that the connector is intended for soldering to a PCB or directly onto the cable.
