SMB M BT 3002 CPS
SMB M BT 3002 CPS

SMB M BT 3002 CPS

₹99

  1. Connector Type:
    • SMB Male BT 3002 CPS: A male SMB connector designed for BT 3002 coaxial cables, using a combination of crimping and soldering for attachment.
  2. Pin Configuration:
    • Crimp Pin: The connector includes a crimp pin that attaches to the center conductor of the BT 3002 cable.
    • Soldering: The connector may also feature soldered contacts for additional stability and conductivity.
  3. Material:
    • Body: Typically made from high-quality metals such as brass or stainless steel, often plated with nickel or gold to enhance conductivity and resist corrosion.
    • Contacts: Internal contacts are made from high-conductivity metals and may be plated to minimize signal loss.
  4. Cable Compatibility:
    • BT 3002: Designed specifically for BT 3002 coaxial cables, which are used in RF and communication systems.
  5. Impedance:
    • 50 Ohms: The connector is typically designed for a 50-ohm impedance, matching the BT 3002 cable to ensure minimal signal reflection and optimal performance.
  6. Frequency Range:
    • High Frequency: Suitable for high-frequency applications, effective up to several GHz depending on the specific connector design.
  7. Installation:
    • Crimping and Soldering: The connector is attached using both crimping and soldering methods. The crimping process secures the cable’s center conductor, while soldering ensures a strong and reliable connection.
    • Tools Required: A crimping tool and soldering equipment are necessary for proper installation.
  8. Applications:
    • Communication Systems: Used in RF communication systems including antennas, transmitters, receivers, and other high-frequency equipment.
    • Broadcasting: Suitable for broadcast equipment where reliable signal transmission is essential.
    • General RF Applications: Ideal for various RF applications requiring a durable and compact connector.
Categories: , , Tag:

The SMB male connector is engineered for BT 3002 cable with a compression (CPS) termination. This connector ensures a stable and secure connection, suitable for RF applications requiring minimal signal loss. It is designed for high-frequency performance, making it ideal for communication systems where reliability is essential. The compression termination provides ease of installation and long-term durability, making it suitable for use in various environmental conditions. |

  • SMB M BT 3002 CPS is a male SMB connector specifically designed for BT 3002 coaxial cables. It features a CPS connection mechanism, combining crimping and soldering to ensure a robust and stable connection.
  • “SMB” refers to the SMB series of connectors, known for their compact size and reliable performance in high-frequency applications.
  • “M” denotes that the connector is male, meaning it has external pins or contacts that mate with female connectors.
  • “BT 3002” specifies that the connector is compatible with BT 3002 coaxial cables, which are often used in various RF and communication applications.
  • “CPS” stands for Crimp Pin Solder, indicating that the connector utilizes both crimping and soldering for secure attachment
